| processor |
| processor family | Intel® Core™ i5 |
| Processor manufacturer | Intel |
| Processor model | i5-8500 |
| Frequency Processor | 3 GHz |
| Processor generation | Intel® 8th Generation Core™ i5 |
| Number of processor cores | 6 |
| Processor number of threads | 6 |
| Maximum processor turbine frequency | 4.1 GHz |
| Processor socket | LGA 1151 (Socket H4) |
| Processor cache | 9 MB |
| Processor cache type | Smart Cache |
| System Bus | 8 GT/s |
| Bus type | DMI3 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Code name processor | Coffee lake |
| Thermal Design Power (TDP) | 65 W |
| Tjunction | 100 ° C |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lines | 16 |
| PCI Express configurations | 1x16, 1x8+2x4, 2x8 |
| Number of installed processors | 1 |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Clock memory speeds supported by processor | 2666 MHz |
| Memory bandwidth supported by the processor (max) | 41.6 GB/s |
| Memory |
| Internal memory | 16 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout | 2 x 8 GB |
| Memory Slots | 4x DIMM |
| Clock speed memory | 2666 MHz |
| Non-ECC | Yes |
| Storage media |
| total storage capacity | 256 GB |
| Type of optical drive | No |
| Storage media | SSD |
| Total capacity of SSDs | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD-vormfactor | 2.5" |
| Integrated memory card reader | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
| Graphic |
| Separate graphics adapter | Yes |
| Built-in graphics adapter | Yes |
| Discreet graphical adapter model | AMD Radeon PRO WX 4100 |
| On-board graphics adapter model | Intel® UHD Graphics 630 |
| Graphic memory | 4 GB |
| Base frequency built-in graphics adapter | 350 MHz |
| Graphics on-board adapter dynamic frequency (max) | 1100 MHz |
| Maximum memory built-in graphics adapter | 64 GB |
| Number of displays supported (by on-board graphics adapter) | 3 |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter OpenGL version | 4.5 |
| On-board Graphic Adapter ID | 0x3E92 |
| Network |
| Ethernet LAN | Yes |
| Ethernet LAN, data transfer rates | 10,100,1000 Mbit / s |
| Cabling technology | 10/100/1000Base-T(X) |
| Gates & Interfaces |
| Number of USB 2.0 ports | |
| Number of ports USB 3.2 Gen 1 (3.1 Gen 1) Type A | 2 |
| Number of portsUSB 3.2 Gen 1 (3.1 Gen 1) Type C | |
| Number of ports USB 3.2 Gen 2 (3.1 Gen 2) Type A | 3 |
| Number of ports USB 3.2 Gen 2 (3.1 Gen 2) Type C | |
| Number of Thunderbolt 3 ports | |
| Number of HDMI ports | |
| Number of USB 3.2 Gen 2.2 Type-C ports | |
| PowerShare | No |
| Number of USB Powershare ports supported | |
| Number of Thunderbolt ports | |
| Number of Thunderbolt 2 ports | |
| Number of Thunderbolt 3 ports with PowerShare support | |
| VGA (D-Sub) port (s) | |
| DVI-poort | No |
| Number of Ethernet LAN (RJ-45) ports | 1 |
| Microphone, line-in input | No |
| Headphone outlets | |
| Combo headphone / microphone port | Yes |
| Serial port (s) | 1 |
| Aan-/uitknop | Yes |
| Design |
| Type of housing | Rack-mounted chassis |
| Color of product | Black |
| Support for placement | Horizontal |
| Number of 2.5" bays | 4 |
| Performance |
| type of product | Workstation |
| Audio system | Waves MaxxAudio Pro |
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
| Software |
| Includes operating system | Windows 10 Pro |
| Architecture operating system | 64-bit |
| OSD Language | English, Spanish, French |
| Processor special features |
| Intel® 64 | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Built-in options available | Yes |
| Intel® InTru ™ 3D Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Clear Video technology | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® TSX-NI | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Stable Image Platform Program (SIPP) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Enhanced Halt State | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID) | Yes |
| Packaging size processor | 37.5 x 37.5 mm |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2015C |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Version Intel® Identity Protection Technology | 1,00 |
| Version Intel® Stable Image Platform Program (SIPP) | 1,00 |
| Version Intel® Secure Key Technology | 1,00 |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® TSX-NI Version | 1,00 |
| ARK ID processor | 129939 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Conflict-free processor | Yes |
| Energy |
| AC | 550 W |
| Environmental requirements |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature | -40 - 65 °C |
| Relative humidity in operation (H-H) | 10 - 85 percent |
| Humidity at storage | 10 - 90 percent |
| Vibrations, in operation | 0.26 G |
| Vibrations during storage | 2 G |
| Shock resistance | 10 G |
| Shock resistance (non-use) | 71 G |
| Weight & dimensions |
| Width | 482 mm |
| Depth | 589.1 mm |
| Height | 42.8 mm |
| Weight | 8.74 kg |
| Contents of the package |
| mouse included | Yes |
| Keyboard included | Yes |
| User guide | Yes |
| Includes power cord | Yes |
| display |
| display included | No |
